Panasonic TH-65PF9UK - Electrical Replacement Parts List

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
F201 HU216005BP CARTRIDGE FUSE 1
F301 HU216005BP CARTRIDGE FUSE 1
F501 HU216002BP CARTRIDGE FUSE 1
F1601,1
602
K5D103BMA001 TIME LAG FUSE HIGH 2
F1701,1
702
K5D502BNA007 AC FUSE 2
A1601,0
2
RA362MSV7 ARRESTOR 2
C002 ECJ1XF1C104Z C 0.1UF, Z, 16V 1
C10 K1MN68BA0076 68P CONNECTOR 1
C11 K1MN20BA0231 20P CONNECTOR 1
C21 K1MN80BA0076 80P CONNECTOR 1
C22 K1MN20BA0231 20P CONNECTOR 1
C24,25 K1MN68BA0076 68P CONNECTOR 2
C31 K1MN80BA0076 80P CONNECTOR 1
C35 K1KA08AA0150 8P CONNECTOR 1
C41 K1MN80BA0076 80P CONNECTOR 1
C42 K1KA08AA0150 8P CONNECTOR 1
C44 K1KA20AA0009 20P CONNECTOR 1
C51 K1MN80BA0076 80P CONNECTOR 1
C52 K1MN20BA0231 20P CONNECTOR 1
C54,55 K1MN68BA0076 68P CONNECTOR 2
C60 K1MN68BA0076 68P CONNECTOR 1
C61 K1MN20BA0231 20P CONNECTOR 1
C201 KZE1E470 C 470U 25V 1
C203,04 RR3DD101K CERAMIC CAPACITOR 2 PAVCA
C205 ECWH12473HV PLASTIC FILM
CAPACITOR
1 PAVCA
C212 ECWH12333HV PLASTIC FILM
CAPACITOR
1 PAVCA
C213,14 KZE1E470 C 470U 25V 2
C215 ECJ2XB1H103K C 0.01UF, K, 50V 1
C216 KZE1H101 C 100UF 50V 1
C251-54 KMQ220821K ELECTROLYTIC
CAPACITOR
4 PAVCA
C255,56 ECQE6223KF P 0.022UF, K,400V 2
C257 ECJ2XB1H103K C 0.01UF, K, 50V 1
C301 KZE1E101 C 100UF 25V 1
C302,03 RR3DD101K CERAMIC CAPACITOR 2 PAVCA
C305 ECWH12333HV PLASTIC FILM
CAPACITOR
1 PAVCA
C351,52 KZE1E182S C 1800UF 25V 2
C354,55 TBB475K1 CERAMIC CHIP
CAPACITOR
2
C356 KZE1E821L C 8200UF 25V 1
C357 ECJ1XB1H104K C 10PF, J, 50V 1 PAVCA
C358 KZE1E101 C 100UF 25V 1
C359 ECJ1XB1H104K C 10PF, J, 50V 1 PAVCA
C360 KZE1E101 C 100UF 25V 1
C361 ECJ1XB1H104K C 10PF, J, 50V 1 PAVCA
C363 KZE1E821L C 8200UF 25V 1
C364 ECJ1XB1H104K C 10PF, J, 50V 1 PAVCA
C365 KZE2A270 C 27UF 100V 1
C366 ECJ2FB1H104K C 0.1UF, K, 50V 1
C401 TAB104K2E CERAMIC CHIP
CAPACITOR
1
C402,03 KMQ2C471H ELECTROLYTIC
CAPACITOR
2 PAVCA
C405 TAB104K2E CERAMIC CHIP
CAPACITOR
1
C412 TBB104K2 CERAMIC CHIP
CAPACITOR
1
C413,14 KZE2A471S C 470UF 100V 2
C415 KZE1H221 ELECTROLYTIC
CAPACITOR
1
C501 ECQU2A473ML P 0.047UF, M,250V 1
C502,03 ECJ2FB1H104K C 0.1UF, K, 50V 2
C504,05 KZE1E470 C 470U 25V 2
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C506 KMQ2W560 ELECTROLYTIC
CAPACITOR
1 PAVCA
C507 KZE1H101 C 100UF 50V 1
C508 MBB474K1 CERAMIC CHIP
CAPACITOR
1
C509 ECJ2XB1H103K C 0.01UF, K, 50V 1
C510 KZE1H101 C 100UF 50V 1
C514 KZE1E470 C 470U 25V 1
C551 ECKENA101KBR C 100P 250V 1
C552 KZE1A152 ELECTROLYTIC
CAPACITOR
1 PAVCA
C555 TBB474K2 CERAMIC CHIP
CAPACITOR
1
C556 KZE1E101 C 100UF 25V 1
C557 TBB475K1 CERAMIC CHIP
CAPACITOR
1
C558 KZE1E101 C 100UF 25V 1
C559-61 ECJ1XB1H104K C 10PF, J, 50V 3 PAVCA
C801 F2H1V221A004 E 220UF, 35V 1
C802 F2H1E471A010 E 470UF, 25V 1
C804 ECJ1VB1H472K C 4700PF, K, 50V 1
C805,06 ECJ1VB1E104K C 0.10UF, K, 25V 2
C807 ECJ3YF1E225Z C 2.2UF, Z, 25V 1
C808 ECJ1VB1E104K C 0.10UF, K, 25V 1
C809 ECJ3YB1C225K C 0.022UF, K, 16V 1
C811 EEVHB1C471 E 470UF, 16V 1
C812 F2H1E471A010 E 470UF, 25V 1
C814 ECJ1VB1H472K C 4700PF, K, 50V 1
C815,16 ECJ1VB1E104K C 0.10UF, K, 25V 2
C817 ECJ3YF1E225Z C 2.2UF, Z, 25V 1
C818 ECJ1VB1E104K C 0.10UF, K, 25V 1
C819 ECJ3YB1C225K C 0.022UF, K, 16V 1
C821 EEVHB1C471 E 470UF, 16V 1
C822 F2H1E471A010 E 470UF, 25V 1
C823 ECJ1XC1H470J C 47PF, J, 50V 1
C824 ECJ1VB1H103K C 0.001UF, K, 50V 1
C825 ECJ1VB1E104K C 0.10UF, K, 25V 1
C827 ECJ3YF1E225Z C 2.2UF, Z, 25V 1
C828 ECJ1VB1E104K C 0.10UF, K, 25V 1
C829 ECJ3YB1E106M C 10 UF, K, 25V 1
C831 EEEHB1C470P C 47PF, J, 16V 1
C832 ECJ1VB1E104K C 0.10UF, K, 25V 1
C833 ECJ1VB1H103K C 0.001UF, K, 50V 1
C834,35 EEEHB1C470P C 47PF, J, 16V 2
C837 F1J0J1060004 C 0.010UF, K, 16V 1
C838 ECJ3YB1C225K C 0.022UF, K, 16V 1
C839 F1J0J1060004 C 0.010UF, K, 16V 1
C840 ECJ3YB1C225K C 0.022UF, K, 16V 1
C841 F1J0J1060004 C 0.010UF, K, 16V 1
C843 ECJ3YB1E106M C 10 UF, K, 25V 1
C844 ECJ3YB1C225K C 0.022UF, K, 16V 1
C845 ECJ3YB1E106M C 10 UF, K, 25V 1
C846 ECJ3YB1C225K C 0.022UF, K, 16V 1
C847 F1J0J1060004 C 0.010UF, K, 16V 1
C848 ECJ3YB1C225K C 0.022UF, K, 16V 1
C850 ECQB1H104JF P 0.1UF, J, 50V 1
C852 ECA1EM471 E 470UF, 25V 1
C854 EEUFC1C471 E 470UF, 16V 1
C855-57 ECJ1VB1H103K C 0.001UF, K, 50V 3
C867 ECJ1VB1E104K C 0.10UF, K, 25V 1
C869 ECJ3YB1C225K C 0.022UF, K, 16V 1
C1530 ECJ3XB0J106M C 10UF, M,6.3V 1
C1601 ECQU2A105ML P 1UF, 250V 1
C1602-
05
ECKENA101KBR C 100P 250V 4
C1608 ECQU2A224ML P 0.22UF, 250V 1
C1613,1
4
MMXC2W474K PLASTIC FILM
CAPACITOR
2 PAVCA
C1619 ECJ2XB1H103K C 0.01UF, K, 50V 1
C1620 ECQE6103KF P 0.01UF, J,630V 1
C1621 ECJ2XB1H102K C 1000PF, K, 50V 1
C1622 KZE1E101 C 100UF 25V 1
17.2. Electrical Replacement Parts List
155
TH-65PF9UK
