Panasonic WR-DA7 - Chapter 7 Equalizer

DA7 Users’ Guide
7
-
1
7
Equalizer
7-1 Overview
This chapter provides information on the EQUALIZER section of the Top
Panel and the [EQUALIZER] window group selections. A 4-band parametric
equalizer is available for each of the 32 channels, each of the 8 buses, and
MASTER L/R. A 2-band parametric equalizer is available for each of the six
aux returns. There are no parametric equalizers provided for the six aux
sends, which is not a problem because you can apply equalization to the
channel prior to assigning an aux send. Each equalizer band has controls for
Q factor, Frequency, and Gain.
The [EQUALIZER] window provides filter type selections for refining the
specific equalization settings. In addition to the default filter type of [PEQ]
(parametric equalizer) filtering, high pass, low pass, shelf high, and shelf low
filter types are available. The [EQUALIZER] window also contains an [A/B]
function area which allows you to compare two equalizer settings for the
selected channel, and a or “clear” function.
Chapter 7
Equalizer
EQUALIZER Section
4
