Panasonic WR-DA7 - Analog Outputs

CHANNEL library 50 registers
EQUALIZER library 50 registers
DYNAMICS library 50 registers
AUTOMATION 4 mix
Ambient operating temperature 0° C ~ 40° C (32° F ~ 104°F)
Dimensions (mm) 698W x 244H x 549.5D
Weight (without options) 23kg (51lbs)
Finish ABS resin (Top Panel), Blue black
Standard Accessories Power Cord, Users’ Guide,
Warranty Card, Registration Card
Analog Inputs (0dB = 0.775 Vrms, 0dBV = 1 Vrms)
Input Source Signal Level (Nominal- Connector
Type Impedance before clipping) Type
CH inputs 1-8 5kΩ mics, 50Ω ~ 600Ω -60dB ~ -46dB XLR 3-31 (bal)
lines, 600Ω +10dB ~ +24dB XLR 3-31 (bal)
CH inputs 9-16 5kΩ mics, 50Ω ~ 600Ω -60dB ~ -46dB TRS phone jack (bal)
lines, 600Ω +10dB ~ +24dB TRS phone jack (bal)
CH Insertion Returns
1 ~ 16 10kΩ lines, 600Ω +4dB ~ +18dB TRS phone jack
(unbal)
2TR B IN(analog)10kΩ lines, 600Ω +4dB ~ +18dB TRS phone jack (bal)
Aux returns 3~6 10k Ω lines, 600Ω +4dB ~ +18dB TRS phone jack
(unbal)
Analog Outputs (0dB = 0.775 Vrms, 0dBV = 1 Vrms)
Input Output Adapted Load Signal Level (Nominal- Connector
Type Impedance Impedance before clipping) Type
MASTER out L/R 150Ω lines 600Ω +4dB ~ +18dB XLR 3-32 (bal)
Aux sends 3~6 75Ω lines 10kΩ +4dB ~ +18dB Phone jack (unbal)
INSERTION 1~16 10Ω lines 10kΩ +4dB ~ +18dB Phone jack (unbal)
REC OUT L/R(analog) 150Ω lines 10kΩ +4dB ~ +18dB TRS phone jack
(bal)
MONITOR A out L/R 150Ω lines 600Ω +4dB ~ +18dB TRS phone jack
(bal)
MONITOR B out L/R 150Ω lines 600Ω +4dB ~ +18dB TRS phone jack
(bal)
Headphones 8Ω phones 40Ω/8Ω 400mW/100mW Stereo phone jack
(unbal)
Appendix F
DA7 Users’ Guide
F
-
3
F
Technical
Specifications
