Compressor
Threshold -60dB ~ 0dB (1dB/step)
Ratio 1.0, 1.1, 1.3, 1.5, 1.7, 2.0, 2.5, 3.0,
3.5, 4.0, 5.0, 6.0, 8.0, 10, 20, ∞ (16 points)
Attack time 0ms ~250ms (1ms/step)
Release time 5ms ~ 2000ms (5ms/step)
Gain 0dB ~ +12dB (0.5dB/step)
Gate
Threshold -80dB ~ -15dB (1dB/step)
Attack Time 0ms ~ 250ms (1ms/step)
Release time 5ms ~ 2000ms (5ms/step)
Expander
Threshold -80dB ~ -15dB (1dB/step)
Ratio 1.0, 2.0, 3.0, 4.0, 5.0, 6.0, ∞
Attack time 0ms ~ 250ms (1ms/step)
Release time 5ms ~ 2000ms (5ms/step)
Range 0dB ~ +40dB (0.5dB/step)
Equalizer
LOW band PEQ (parametric equalizer) type: Q = 0.5 ~ 50 (41 steps)
F = 20Hz ~ 20kHz (1/12 oct step)
G = ± 15dB (0.5dB/step)
LOW band SHL (shelving low) type: F = 20Hz ~ 1.6kHz (1/12 oct step)
G = ± 15dB (0.5dB/step)
LOW band HPF (high-pass) type: F = 20Hz ~ 1.6kHz (1/12 oct step)
LOW-MID band PEQ type: Q = 0.5 ~ 50 (41 steps)
F = 20Hz ~ 20kHz (1/12 oct step)
G = ± 15dB (0.5dB/step)
HIGH-MID band PEQ type: Q = 0.5 ~ 50 (41 steps)
F = 500Hz ~ 20kHz (1/12 oct step)
G = ± 15dB (0.5dB/step)
HIGH band PEQ type: Q = 0.5 ~ 50 (41 steps)
F = 500Hz ~ 20kHz (1/12 oct step)
G = ± 15dB (0.5dB/step)
HIGH band SHH (shelving high) type: F = 1kHz ~ 20kHz (1/12 oct step)
G = ± 15dB (0.5dB/step)
HIGH band LPF (low-pass) type: F = 1kHz ~ 20kHz (1/12 oct step)
Delay 0 ~14,400 samples/0 ~300ms (Fs = 48kHz), 0 ~ 326ms (Fs = 44.1kHz)
Phase normal/reverse (switchable)
Stereo meter Bar graph type LED, Left and Right, 20 points for each
VU or PPM (selectable)
Peak hold on/off, ∞
Fader 100mm motor fader (x21), + 10db ~ -90dB -∞ dB
Display LCD, 320x240 dot, with backlight
Memory SCENE MEMORY(Snapshot) 50 registers
Appendix F
DA7 Users’ Guide
F
-
2
F
Technical
Specifications
