Panasonic WR-DA7 - TDIF (TASCAM Digital Audio Interface) Card, WR-TDIF

17-2 TDIF (TASCAM Digital Audio Interface) Card,
WR-TDIF
Use the TDIF card with the DA7 to connect an external digital tape recorder,
such as the TASCAM DA-88.
DA88 + DA7
This diagram will help you set up a pair of DA88 DTRs with the DA7 using
one of the DA88s as the Word Clock master.
Chapter 17
DA7 Users’ Guide
17
-
5
17
Options
WR-TDIF
TDIF Digital I/O Card
TASCAM DIGITAL AUDIO INTERFACE
(TDIF-1)
TDIF Digital I/O Card
DA88 + DA7 GRAPHIC
DA88 ID1
DA88 ID0
SYNC IN
SYNC OUT
WCK master
WCK OUT
EFX Device
DAT
S/PDIF/ I/O
AES/EBU I/O
WCK IN
WR-
TDIF
WR-
TDIF
DA7
TO PC
CR monitor out
PC
Power amp
SP SP
I/O (SYNC OUT need terminator)
I/O (SY88 option installed)
MMC
MTC
MIDI OUT
MIDI IN
You will need to follow these instructions carefully, otherwise
your system may not function properly.
