Panasonic WR-DA7 - Optional Accessories

Appendix F
DA7 Users’ Guide
F
-
5
F
Technical
Specifications
TO PC
in/out: In and Out
Connector: Mini-DIN Connector 8P
RS422/485
in/out: In and Out
Connector: D-sub 9P
FOOT SWITCH
in/out: In
Level: TTL level, Normally Open (Unlatch type)
Connector: Phone jack
Optional Accessories
Meter Bridge
Type: Bargraph LED, 26 channels, 15 points for each
Format: RAMSA original Level NET II
Power: DC 7v
Connector: D-sub 15P
ADAT Interface card (8 in / 8 out)
Type: ADAT (DIRECT OUT / BUS / AUX / MASTER, Input 9-32)
in/out: In and Out
Connector: Optical
TDIF Card (8 in / 8 out)
Type: TDIF (DIRECT OUT / BUS / AUX / MASTER, Input 9-32)
in/out: In and Out
Format: TDIF-1
Connector: D-sub 25P (in and out)
AES/EBU Card (8 in / 8 out)
Type: AES/EBU/SPDIF
Signal type: RS422
Connector: D-sub 25P (in and out)
