Digital In and Out
2TR IN (INPUT 15,16)
in/out: In
format: IEC 958 Professional (AES/EBU) or Consumer (S/PDIF)
Level: RS-422 (AES/EBU) or 0.5v [pp]/75Ω (S/PDIF)
Connector: XLR 3-31
REC OUT
in/out: Out
format: IEC 958 Professional (AES/EBU) or Consumer (S/PDIF) switchable
Level: RS-422 (AES/EBU) or 0.5v [pp]/75Ω (S/PDIF)
Connector: XLR 3-32
AUX RETURN 1/2
in/out: In
format: IEC 958 Consumer (S/PDIF)
Level: 0.5v [pp]/75Ω
Connector: RCA pin jack
AUX SEND 1/2
in/out: Out
format: IEC 958 Consumer (S/PDIF)
Level: 0.5v [pp]/75Ω
Connector: RCA pin jack
WORD CLOCK IN
in/out: In
Level: TTL/75Ω switchable
Connector: BNC
WORD CLOCK OUT/THROUGH
in/out Out
Level: TTL/75Ω, Pass-through (75Ω OFF) or termination (75Ω ON)
Connector: BNC
MIDI IN
in/out: In
Format: MIDI
Connector: DIN Connector 5P
MIDI OUT
in/out: Out
Format: MIDI
Connector: DIN Connector 5P
