AUDIO INPUT
• Microphones . . . . . . . . . . . . . . . . . INPUTS 1-4
• Bass guitar . . . . . . . . . . . . . . . . . . INPUT 8
• Guitar . . . . . . . . . . . . . . . . . . . . . . INPUT 9
• Drum machine . . . . . . . . . . . . . . . INPUTS 13, 14
• Keyboard . . . . . . . . . . . . . . . . . . . . INPUTS 15, 16
INSERT
• Compressor/pre-amp . . . . . . . . . . INS 1-16
AUXILIARY
• Digital reverb . . . . . . . . . . . . . . . . AUX 1/2 SEND and RETURN
• EFX (Analog) . . . . . . . . . . . . . . . . AUX 3/4, 5/6 SEND and RETURN
• Cassette tape recorder . . . . . . . . . REC OUT/2TR B IN
• DAT . . . . . . . . . . . . . . . . . . . . . . . . DIGITAL IN/OUT
• 3 Multi-track recorders . . . . . . . . . ADAT option cards in SLOTS 1, 2, and 3
AUDIO OUTPUT
• Control room monitors . . . . . . . . . MONITOR A OUT
• Studio monitors/headphones . . . . MONITOR B OUT
• Control room headphones . . . . . . HEADPHONE OUTPUT
