Appendix B
DA7 Users’ Guide
B
-
4
B
LCD Screen
Displays
Master Display
Section
Meter
Button
Input 1-32 Window Bus/Aux Window Slot Window
Return to
First
Window
Input 1-32 Window
Bus/Aux Window
Slot Window
METER, MASTER DISPLAY SECTION
