pm
Selectable Channel (pl)
Appendix G
DA7 Users’ Guide
G
-
10
G
MIDI Chart
NRPN (Parameter)
ALLINPUT 1-32
Data (dm, dl)
5BH EQ ON 1-32 1-6 – 1-8 L/R OFF/ON
5CH EQ LOW BAND FILTER TYPE 1-32 1-6 – 1-8 L/R PEQ/HPF/SHL
5DH EQ HIGH BAND FILTER TYPE 1-32 1-6 – 1-8 L/R PEQ/LPF/SHH
5EH EQ LOW BAND Q 1-32 1-6 – 1-8 L/R 0.5..50
5FH EQ LOW BAND F 1-32 1-6 – 1-8 L/R PEQ:20..20kHz
HPF,SHL:20..1.6kHz
60H EQ LOW BAND G 1-32 – – 1-8 L/R PEQ,SHL:–15..15dB
HPF:OFF/ON
61H EQ L-MID BAND Q 1-32 – – 1-8 L/R 0.5..50
62H EQ L-MID BAND F 1-32 – – 1-8 L/R 20 to 20kHz
63H EQ L-MID BAND G 1-32 – – 1-8 L/R –15..15dB
64H EQ H-MID BAND Q 1-32 – – 1-8 L/R 0.5..50
65H EQ H-MID BAND F 1-32 – – 1-8 L/R 500..20kHz
66H EQ H-MID BAND G 1-32 – – 1-8 L/R –15..15dB
67H EQ HIGH BAND Q 1-32 1-6 – 1-8 L/R 0.5..50
68H EQ HIGH BAND F 1-32 1-6 – 1-8 L/R PEQ:500..20kHz
LPF,SHH:1k.20kHz
69H EQ HIGH BAND G 1-32 1-6 – 1-8 L/R PEQ,SHH:–15..15dB
LPF:OFF/ON
6AH DYN ON,FUNCTION 1-32 – – 1-8 L/R OFF/COMP+GATE/EXP
6BH DYN STEREO LINK 1-32 – – 1-8 L/R OFF/LEFT/RIGHT/BOTH
6CH DYN POSITION 1-32 – – 1-8 L/R POST EQ/PRE EQ
6DH DYN GATE THL 1-32 – – 1-8 L/R OFF,–80..–15dB
6EH DYN GATE ATTACK 1-32 – – 1-8 L/R 0..250ms
6FH DYN GATE RELEASE 1-32 – – 1-8 L/R 5..2000ms
70H DYN COMP/EXP THL 1-32 – – 1-8 L/R COMP:–40..0dB
EXP:–80..–15dB
71H DYN COMP/EXP RATIO 1-32 – – 1-8 L/R COMP:1:1..infinity:1
EXP: 1:infinity..1:1
72H DYN COMP/EXP ATTACK 1-32 – – 1-8 L/R 0..250ms
73H DYN COMP/EXP RELEASE 1-32 – – 1-8 L/R 5..2000ms
74H DYN COMP/EXP GAIN/RANGE 1-32 – – 1-8 L/R COMP:0:12dB(GAIN)
EXP:0..40dB(RANGE)
75H SELECTED CH 1-32 1-6 1-6 1-8 L/R –
76H AUTOMATION REC CH 1-32 1-6 1-6 1-8 L/R OFF/ON
77H AUTOMATION MANUAL CH 1-32 1-6 1-6 1-8 L/R OFF/ON
78H OSCILLATOR ASSIGN CH – – 1-6 1-8 L/R OFF/ON
79H CH LIBRARY RECALL CH 1-32 1-6 1-6 1-8 L/R –
7AH EQ LIBRARY RECALL CH 1-32 1-6 – 1-8 L/R –
7BH DYN LIBRARY RECALL CH 1-32 – – 1-8 L/R –
7CH SOLO MONITOR CH 1-32 1-6 1-6 1-8 – OFF/ON
7DH SCENE MEMORY PROTECT CH 1-32 1-6 1-6 1-8 L/R OFF/ON
7EH SCENE MEMORY FADE CH 1-32 1-6 1-6 1-8 L/R OFF/ON
7FH SYSTEM CURRENT
Assignment of NRPN Parameter LSB (pl) for Selecting Channel
20H - 3FH
INPUT AUX RTN AUX SND BUS MASTER
Parameter
Assignment of NRPN Parameter MSB (pm) [2/2]
58H - 5DH 64H - 69H 70H - 77H 78H 7FH
AUX RTN 1-6 AUX SND 1-6 BUS 1-8 MASTER L/R
