24
G
MIDI Chart
Send
0
Code
30Hz
Code
SOURCE
[SOURCE] of Oscillator
<Table>
Value
ValueSend
Dec Hex Dec Hex
00H 0 00H
Receive
1 01H 1 01H 60Hz
2 02H 2 02H 100Hz
3 03H 3 03H 300Hz
4 04H 4 04H 1kHz
5 05H 5 05H 4kHz
6 06H 6 06H 10kHz
7 07H 7 07H 15kHz
8 08H 8-127 08H-7FH PINK
Receive
Dec Hex Dec Hex
0 00H 0 00H INT44.1K
INT48K
WCK IN
VSYNC
2TR IN A
SLOT1
SLOT2
SLOT3
1 01H 1 01H
2 02H 2 02H
3 03H 3 03H
4 04H 4 04H
5 05H 5 05H
6 06H 6 06H
7 07H 7-127 07H-7FH
*
NRPN : Data LSB = Code, Data MSB (dm) is 00H fixed.
WORD CLOCK SOURCE
[WORD CLOCK SOURCE] of Digital Input
<Table>
*
NRPN : Data LSB = Code, Data MSB (dm) is 00H fixed.
TANDEM DELAY TIME
[TANDEM DELAY TIME] of Tandem Connection
<Range>
0..200 [sample]
<Expression>
Control Change : Value = Code
*
2, Code = INT(Value / 2)
NRPN : Value = dm
*
80H + dl, dm = INT(Value / 80H), dl = Value – dm
*
80H
NRPN (Data)
