DA7 Users’ Guide
Index
B
[BATTERY] area
OSC/BATT window 16-8
[BAUD RATE] area
[MIDI>SETUP] window
11-2
Backup
bulk 1-8
BUF CLR button
[SETUP] window,
AUTOMATION button 14-3
BULK OUT button 1-8
BUS ASSIGN section. See
PAN/ASSIGN/SURROUND 2-
5, 2-9
BUS Fader Strip
BUS ASSIGN section
[BUS/AUX] meter window
[MIDI>BULK] window
11-10
[BUS/AUX] meter window
METER group windows 5-
18
C
Cancel button 11-12
[MIDI>BULK] window
11-10
CH LIB button
[MIDI>BULK] window
11-10
CH or AUX 2 LED
LED status indicator 6-4
Channel Fader Strip 2-5, 2-7
[Channel library number/title
21:CHLIB NAME] 5-2, 5-12
[MIDI>BULK] window
11-10
Channel selection field 2-5, 2-7
LCD screen, Display Bridge 2-
21
Channel Strip
fader 6-6
FLIP LED button 6-5
LED status indicators 6-4—
6-5
MIC/LINE INPUT knob
6-3
ON LED button 6-6
PEAK/SIGNAL LED 6-3
SELECT LED button 6-6
SOLO LED button 6-5
Channel type field 6-3
LCD screen, Display Bridge
2-21
[CHANNEL] window
[ASSIGN] area 5-9—5-10
[AUX SEND] area ([AUX1] to
[AUX6]) 5-4
[CH] area 5-11
[DYL] area 5-11
[DYN] area 5-10
[EQUALIZER] area 5-7
[FADR GRP] area 5-6—5-7
[FADR] button 5-20
[GAIN] area 5-4
[INS] area 5-5
[LEVEL] area 5-6
[LINK] area 5-5—5-6
[LINK] button 5-21
multi-channel view 5-2
[MUTE GRP] area 5-7
[MUTE] button 5-21
[PAN/BAL] area 5-8—5-9
Gain Reduction meter [GR]
area 5-6
Multi CH View button 5-20
Phantom Power [+48V] area
5-3
Phase [PH] area 5-4
CLEAR ALL button
[PRG ASGN] window 11-6
CLEAR button
[DYNAMICS] library 9-16
[SETUP] window,
AUTOMATION button 14-3
EQUALIZER Library window
7-9
Library windows 5-15
Clock InputRear Panel 2-29
Clock Output
Rear Panel 2-29
Clock Terminating Switch
Rear Panel 2-29
CLR ALL button
[SETUP] window,
AUTOMATION button 14-2
FADE TIME window 15-5
SCENE MEMORY section
15-3
SOLO/MON window 16-5
[COMMAND MODE] area 11-19
[MIDI RMT] windows 11-14
Communication status indicator
LCD screen, Display Bridge 2-
21
COMP button
[DYNAMICS] window, multi-
channel view 9-13
Compressor operations
[DYNAMICS] window 9-11
Configuration 1-9, 16-9—16-12
[CONFIGURATION] area selections
16-9—16-10
[NEW PASSWORD] field
16-11
[PASSWORD] field 16-11
10KEY SCENE RECALL
Selection 16-10
DYN RANGE dBFS selection
16-9
LOAD CONFIRMATION
selection 16-10
MOTOR FADER selection
16-10
RAMSA NET PROGRAM CHG
selection 16-10
RMT SW POLARITY selection
16-10
SAVE CONFIRMATION
selection 16-10
SYNC WARNING selection
16-10
Configuration (CONFIG) window
1-8
AUTO CHANNEL SELECT
selection 16-9
