Chapter 2
DA7 Users’ Guide
2
-
17
2
DA7 Tour
UTILITY Button
Pressing the UTILITY button will display the [UTILITY] window group on
the LCD screen in the Display Bridge. The window displayed will be
determined by the window selection buttons at the bottom of the window.
Pressing the UTILITY button again will cycle the window selections:
[OSC_BATT], [CONFIGuration], [USER CuSToM].
See Chapter 16, Utility and Solo Monitor for additional information.
MIDI Button
Pressing the MIDI button will display the [MIDI] window group on the LCD
screen in the Display Bridge. Pressing the MIDI button again will cycle the
window selections: [SETUP], [PRoGram ASsiGN], [ConTRoL ASsiGN],
[BULK], [REMOTE].
See Chapter 11, MIDI for additional information.
D-I/O Button
Pressing the D-I/O button will display the [D-I/O] (Digital Input/Output)
window group on the LCD screen in the Display Bridge. Pressing the D-I/O
button again will cycle the window selections: [INPUT SET], [TO SLOT],
[DITHER].
See Chapter 12, D-I/O for additional information.
GROUP Button
Pressing the GROUP button will display the [GROUP] window selections on
the LCD screen in the Display Bridge. Pressing the GROUP button again
will cycle the window selections: [FADER GRouP], [MUTE GRouP],
[LINK/STR].
See Chapter 13, Group for additional information.
AUTOMATION Button
Pressing the AUTOMATION button will display the [AUTOMATION] window
group on the LCD screen in the Display Bridge. Pressing the AUTOMATION
button again will cycle the window selections: [SETUP], [EXECUTE],
[EVenT EDIT] .
See Chapter 14, Automation for more information.
SOLO MONITOR Button
This button displays Solo Monitor mode, Talk back assignment, and
Surround Monitor.
See Chapter 16, Utility and Solo Monitor for additional information.
