Chapter 3
DA7 Users’ Guide
3
-
15
3
Quick Start
Analog 4-Track Sends and Returns
Connect the output
_
Connect the stereo 1/4” TRS connectors (with
mono Y connections) to the AUX SEND 3/4 and 5/6 outputs on the
Rear Panel of the DA7. Connect the four mono connectors to inputs 1
through 4 of your 4-track tape machine.
Connect the input
_
Connect the output channels of the tape machine
to AUX RETURN 3/4 and 5/6 on the Rear Panel of the DA7. They could
be connected to four separate input channels.
Assign channel outputs
_
In the [CHANNEL] window for each channel,
assign the desired aux outputs and levels.
Activate the AUX/BUS Fader Layer
_
Press the AUX/BUS Fader Layer
LED button (orange).
Send the signal out
_
Turn on the AUX SEND 3,4,5 and 6 Channel
Strips by pressing their ON buttons (red), and raise the faders to send
the signal to your tape deck.
Record the source material on tape.
Listen to tape playback
_
Turn on the AUX RTN 3,4,5 and 6 Channel
Strips, assign an output, and raise the faders to hear the tape output
signal.
7
6
1
3
4
5
2
