Parker AC10 series Quick Start Guide

Function
Code
Function Denition Setting Range
Mfr’s Value Change
F316
DI1 terminal function
setting
0: No function
1: Run
2: Stop
3: Multi-stage speed 1
4: Multi-stage speed 2
5: Multi-stage speed 3
6: Multi-stage speed 4
7: Reset
8: Free stop (coast
stop)
9: External coast stop
10: Accel/decel hold
11: Forward run
jogging
12: Reverse run
jogging
13: Increase freq UP
14: Decrease freq
DOWN
15: “FWD” terminal
16: “REV” terminal
17: Three-line type
input “X” terminal
18: Accel/decel time
switchover 1
19-58 refer to product
manual for additional
settings
11 √
F317
DI2 terminal function
setting
9 √
F318
DI3 terminal function
setting
15 √
F319
DI4 terminal function
setting
16 √
F320
DI5 terminal function
setting
7
F321
DI6 terminal function
setting
8
F322
DI7 terminal function
setting
0
F323
DI8 terminal function
setting
0 √
F324
Free stop (coast
stop) terminal logic
0: Positive logic (low
level = True);
1: Negative logic
(high level = True)
0 X
F325
External coast stop
terminal logic
0 X
F326 Watchdog time 0.0-3000.0 10.0 √
F327 Stop mode
0: Free stop (coast
stop)
1: Decel to stop
0 X
F328 Terminal lter times 1-100 10 √
F329 Reserved
Parameter List and Default Settings
10-8

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
