Page #48 background imageLoading...
Page #48 background image
Function
Code
Function Denition Setting Range
Mfr’s Value Change
F330
Diagnostics of DIx
terminal
Read-only
D
F331 Monitoring AI1 Read-only
D
F332 Monitoring AI2 Read-only
D
F335
Relay output
simulation
Setting range:
0: Output true.
1: Output false.
0 X
F336
DO1 output
simulation
0 X
F338
AO1 output
simulation
Setting range:
0-4095
0 X
F339
AO2 output
simulation
Setting range:
0-4095
0 X
F340
Selection of
terminal negative
logic
0: None
1: DI1 negative
logic
2: DI2 negative
logic
4: DI3 negative
logic
8: DI4 negative
logic
16: DI5 negative
logic
32: DI6 negative
logic
64: DI7 negative
logic
128: DI8 negative
logic
0
