Parker AC10 series

Function
Code
Function Denition Setting Range Mfr’s Value Change
F807 Rotor Resistance Ω
0.001-65.53 Ω (22 kw
and below)
0.1-6553 mΩ (above
22 kw)
Subject
to inverter
model
oX
F808
Leakage
Inductance(mH)
0.01-655.3 mH (22kw
and below)
0.001-65.53 mH (above
22kw)
Subject
to inverter
model
oX
F809 Mutual Inductance(mH)
0.01-655.3 mH (22kw
and below)
0.001~65.53 mH
(above 22kw)
Subject
to inverter
model
oX
F810 Motor Rated Freq 1.00-590 Hz 50.00 oX
F812 Pre-exciting Time 0.000-30.00 s 0.30 √
F813
Rotary Speed Loop
KP1
0.01-20.00 (22 kw and
below)
1-100 (above 22 kw)
Subject
to inverter
model
o√
F814 Rotary Speed Loop KI1
0.01-2.00 (22 kw and
below)
0.01-10.00 (above 22
kw)
Subject
to inverter
model
o√
F815
Rotary Speed Loop
KP2
0.01-20.00 (22 kw and
below)
1-100 (above 22 kw)
Subject
to inverter
model
o√
F816 Rotary Speed Loop KI2
0.01-2.00 (22 kw and
below)
0.01-10.00 (above 22
kw)
Subject
to inverter
model
o√
F817
PID Switching
Frequency 1
0-F111 5.00 √
F818
PID Switching
Frequency 2
F817-F111 50.00 √
F819-
F860
Reserved
Subject
to inverter
model
√
F870
PMSM back
electromotive force (mV/
rpm)
0.1-999.9
Subject
to inverter
model
o
10-17 Parameter List and Default Settings
