Function
Code
Function Denition Setting Range Mfr’s Value Change
FA01
PID reference signal
source
0: FA04
1: AI1
2: AI2
0 X
FA02
PID feedback signal
source
1: AI1
2: AI2
0
FA03
Max limit of PID output
(%)
FA04-100.0 10.00
FA04 PID Digital reference (%) FA05-FA03 50.0
FA05
Min limit of PID output
(%)
0.0-FA04 0.0
FA06 PID polarity
0: Positive feedback
1: Negative feedback
1 X
FA07
Sleep function
selection
0: Enabled 1: Disabled 0 X
FA09
PID Min output
frequency (Hz)
Max (F112, 0.1)-F111 5.00
FA10 Sleep delay time (s) 0-500.0 15.0
FA11 Wake delay time (s) 0.0-3000 3.0
FA18
Whether PID target is
changed
0: Disabled 1: Enabled 1 X
FA19 Proportion Gain P 0.00~10.00 0.3
FA20 Integration time I (s) 0.0~100.0S 0.3
FA21 Differential time D (s) 0.00~10.00 0.0
FA22 PID sampling period (s) 0.1-10.0s 0.1
FA29 PID dead time (%) 0.0-10.0 2.0
FA58
Fire pressure target
value (%)
0.0-100.0 80.0
FA59 Emergency re mode
0: Disabled
1: Emergency re mode
1
2: Emergency re mode
2
0
FA60
Emergency re mode
frequency
F112-F111 50.0
FA61 Reserved
FA62
When emergency
re control terminal
transitions false
0: Inverter cannot be
stopped manually
1: Inverter can be
stopped manually
0 X
FA63-
FA80
Reserved
10-19 Parameter List and Default Settings
