5.8 Connect input and output contacts
In- and output signals can be connected to the terminal strip on the
printed circuit board (refer to §3.3).
Fig.5-5: Printed circuit board
Terminal strip
K5
K6
K7 K8
UA1
UA2
ID1
PI1
PI2
TI/TT
QAIh/QT
SD-card
Transformer
Power supply
PCB
Fuse
T1,25A/250V
Batter
y
