PCAN-Ethernet Gateway FD DR – User Manual
36
Send CAN > IP: With a Send route the data of a CAN channel is
forwarded over the IP interface. If other PCAN-Gateways were
discovered during a broadcast scan, they can be selected for the
destination of the route. On the page
Routing > Scan for Devices
you can search for other PCAN-Gateways in the network.
Status:
Use this setting to determine the state of the route after it is created.
Ticking the checkbox will have the effect of immediately activating
the route after the completed form is saved. Port 45321 is required
for the transmission of status information.
PCANGateway handshake off: (Expert mode only) If this checkbox
is active, no handshake will be performed and therefore no status
information will be gathered for this route. Use this option for
communication with your own application
1
.
CAN Interface:
Choose one of the available CAN channels. The configuration of the
CAN interfaces is done on the page
Network > CAN .
IP Interface:
IP Address Source: This field only appears when PCAN-Gateways
were detected during a network broadcast scan and the direction
“Send CAN> IP" is selected.
Select the desired device from this drop-down menu. The following
IP address is automatically set to the appropriate value. If you prefer
to enter the IP address yourself, select "Manual Input".
1
For information about the data protocol see the PCAN-Gateway developer
documentation.
