PCAN-Ethernet Gateway FD DR – User Manual
47
CAN FD: Use the checkbox to activate or deactivate the CAN FD
support. With this, the setting for the data bit rate is enabled or
disabled.
Bit Rate Definition: (Expert mode only) With this selection you can
determine the mode to be used to set bit rates.
Selected from standard list: This is the default mode which is
used if the Expert mode is switched off. The bit rates can be
selected from standard selection lists
Set with register values: This is an option to set custom bit rates.
If selected, forms with input fields for the register values of the
nominal bit rate and the data bit rate appear. For details, see the
following section
Configuring Custom Bit Rates with Register
Values
Set with register string: This is an option to set custom bit rates.
If selected, a single input form for a register string appears. For
details, see the following section
Configuring Custom Bit Rates
with a Register String
Clock Frequency: Select the CPI clock frequency for this CAN
channel from the selection list.
This selection affects the available bit rates when using the first bit
rate definition mode
Selected from standard list and the custom bit
rate calculation when using the second bit rate definition mode
Set
with register values
.
Nominal Bit Rate: For setting the nominal bit rate, click the drop-
down menu and select the value that is used on the connected CAN
bus.
