Peak PCAN - Page 72

PCAN-Ethernet Gateway FD DR – User Manual
72
Microcontroller
Clock frequency 1 to 1.5 GHz
RAM 1 GByte DDR3-1333 (667 MHz)
Firmware upload Via web interface
Memory
Type Internal, eMMC
Memory size 2 GByte
Dimensions
Size 45.2 x 99 x 114.5 mm (B x H x T)
Weight 250 g
Environment
Operating temperature -40 - 70 °C (-40 – 158 F)
Cooling Fan of the SEPA
®
MF20C05 series, activation
when a temperature limit is exceeded
Temperature for storage and
transport
-55 - 125 °C (-67 – 257 F)
Relative air humidity 15 - 90 %, non-condensing
Ingress protection
(DIN EN 60529)
IP20
Conformity
EMV EU Directive 2014/30/EU
DIN EN 61326-1:2013-07
RoHS 2 EU Directive 2011/65/EU
DIN EN 50581 VDE 0042-12:2013-02
