pellenc C45 - Description and Technical Characteristics

PRUNING SHEARS C45, C45-P150, C45-P200
163529-D
3. DESCRIPTION AND TECHNICAL CHARACTERISTICS
3.1. DESCRIPTION OF THE TOOL
3.1.1. DESCRIPTION OF ONLY THE TOOL
1. Upper conductive pad
2. Blade pin
3. Nut
4. Washer
5. Knurled adjustment washer
6. Blade
7. Hook
8. Mode indicator LED (left side of the tool)
9. Guard
10. Drive trigger
11. Activ' Security indicator LED (right side of the tool)
12. Optical sensor
13. Waste evacuation system
14. Lower conductive pad
15. Power cord connector
13
