pellenc C45 - Greasing the Blade; Cleaning the Tool

PRUNING SHEARS C45, C45-P150, C45-P200
163529-D
6.4.2.2.FITTHEBLADEANDPINSOFTHETOOLWITHAP150ORP200POLE
Note
To remove the blade, the pins and change the worn parts of the tool equipped with a P150 or P200 pole, see
6.4.2.1. Remove the blade and pins from the tool equipped with a P150 or P200 pole, page 40.
1. Repeat points 1 to 14 of the procedure for fitting the
blade and pins of the tool alone.
See 6.4.1.2. Fit the blade and pins of the tool alone,
page 39.
2. Put the cutting head cover (2) on the tool.
3. Tighten the two screws (1) using a Torx T10 screw-
driver to secure the position of the cutting head cov-
er (2).
6.5. GREASING THE BLADE
1. Bring the supplied grease gun (2) into contact with
the tool's blade pin (1) by pressing once until the
grease appears between the blade (3) and the hook
(4).
2. Remove the grease gun (2).
6.6. CLEANING THE TOOL
Avoid the formation of abrasive paste (oil + soil) as much as possible by frequent cleaning. To do so:
• Clean the front of the tool with a cloth and compressed air, avoid solvents such as: trichloroethylene, white spirit,
petrol, etc.
• Grease the blade and blade pins lightly but often with the grease gun supplied, see 6.5. Greasing the blade,
page 41.
41
