Performance Check
General Information
WARNING: Before turning on the in-
strument, ensure that it has been
installed in accordance with the In-
s
tallation Instructions outlined in
Cha
pter 1 of the User's Manual.
This performance procedure is intended for:
checking the instrument's specification.
incoming inspection to determine the ac-
ceptability of newly purchased
instruments and recently recalibrated
instruments.
checking the necessity of recalibration
after the specified recalibration intervals.
NOTE: The procedure does not check every
facet of the instrument's calibration;
rather, it is concerned primarily with
those parts of the instrument which are
essential for determining the function of
the instrument.
It is not necessary to remove the instrument
cover to perform this procedure.
Preparations
Power up your instrument
at least 30 minutes before
checking to let it reach
normal operating
temperature. Failure to do
so may result in certain test steps not meeting
equipment specifications.
Test Equipment
Type of Equipment
Required Specifications
Reference Oscillator
10 MHz, 1*10
-8
(e.g. 6688) for calibrating the standard oscillator
10 MHz, 1*10
-9
(e.g. 6689) for calibrating Opt 30/90 & Opt 40/90
Voltage Calibrator
DC -50 V to +50 V (e.g. 5500) for calibrating the built-in voltage reference,
alternatively corresponding DC power supply + DVM with uncertainty <0.1 %
LF Synthesizer
Square/ Sine up to 10 MHz, 10
V
RMS
Pulse Generator
2 ns rise time, 5 V peak, >10 MHz, continuous & one-shot trigger
Oscilloscope
350 MHz, <3% voltage uncertainty
RF Signal Generator
0.1 to 3, 8, 20, 27, 40, 46, 60 GHz dep. on RF input, 10 MHz ext.ref.
Power Splitter
50 6dB BNC
T-piece
BNC
Termination
50 feed through BNC
Low-pass Filter
50 kHz (for 1 M) load
BNC Cables
5 to 7 pcs of suitable lengths
Table 7-1
Recommended equipment for calibration and performance check.
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
7-2
