Pendulum CNT-90 Series User Manual

Measuring Functions
Totalize
[CNT-91(R) only]
Totalize in General
The Totalize functions add up the number of
trigger events on the two counter inputs A
and B. Several combinations of them are
theoretically possible. Five have been realized
and made available by entering the Totalize
menu.
In addition to controlling the gate manually
by toggling
HOLD/RUN you can also open
and close the gate by using the arming
facilities under
SETTINGS. The different
functions are described below.
The display is updated continually while the
gate is open. Events are accumulated during
consecutive open periods until
RESTART is
pressed.
The manual Totalize functions can
not be used in conjunction with the
Statistics functions and parameters
like block and pacing. Nor does Auto
Trigger work the normal way. An Auto
Once is performed instead before the
start of a measurement in order to
calculate suitable trigger levels once.
TOT A MAN
This mode enables you to totalize (count) the
number of trigger events on Channel A.
Aux- iliary calculated parameters are
A-B
and A/B. Start/Stop is manually controlled
by toggling the key
HOLD/RUN, and the
counting regis- ters are reset by pressing
RESTART.
TOT B MAN
This mode enables you to totalize (count) the
number of trigger events on Channel B.
Aux- iliary calculated parameters are A-B
and A/B. Start/Stop is manually controlled
by toggling the key
HOLD/RUN, and the
counting regis- ters are reset by pressing
RESTART.
TOT A+B MAN
This mode enables you to calculate the sum
of trigger events on Channel A and Channel
B. Auxiliary parameters are
A and B.
Start/Stop is manually controlled by toggling
the key HOLD/RUN, and the counting
registers are reset by pressing
RESTART.
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
4-24
