Pendulum CNT-90 Series User Manual

Specifications
Max. Voltage w/o
Damage:
12 Vrms, PIN diode prot.
Connector:
Type N female
Rear Panel Inputs & Outputs
Ref. Input::
1, 5 or 10 MHz;
0 . 1 - 5 V
rms
sinewave;
impedance >1 k
Ref.
Output:
1x100kHz, 1x1MHz,
Outputs:
1x5MHz and 2x10 MHz
Output level:
>1 Vp-p into 50  load 1
Vrms
typical
Arming Input (E):
Arming of all meas. func.
Freq. Range:
DC - 80 MHz
Trigger Level:
TTL, 1.4 V nom.
Trigger Slope:
Positive or negative
Pulse Output Pulse Out, Gate Open,
Mode:
Alarm Out
Period:
20 ns - 2 s in 10 ns incr.
Pulse Width:
10 ns - 2 s in 10 ns incr.
Output Level:
TTL levels in 50 , 2 n s
rise
time
Connectors:
BNC
Auxiliary Functions
Trigger Hold-Off
Time Delay
20 ns - 2 s, 10 ns resol.
Range:
External Start/Stop Arming
Modes:
Input Channels:
Max. Rep. Rate for
Arming Signal
Channel A, B:
Channel E:
Start Time Delay
Range:
Stop Time Delay*
Range:
Start arming, stop arming,
start and stop arming
A, B, E (EXT ARM)
160 MHz
80 MHz
10 ns - 2 s, 10 ns resol.
20 ns - 2 s, 10 ns resol.
* Stop Time Delay can only be used in
conjunction with the non-manual
Totalize Functions.
Statistics
Functions:
Maximum, minimum, mean,
Δ
max-m
i
n
, standard deviation,
Allan deviation
Display:
Numeric or numeric +
Graphic:
Sample Size:
Max. Sample
Rate:
graphic
Histogram & trend plot, auto
scaled
2 to 2*10
9
250 kSa/s measured, 2 kSa/s
calculated, depending on meas.
function and graphics
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
8-52
