Timebase
Reference:
Display
Hold:
Digit
Blanking:
Limit
Alarm:
Limit
Values:
Settings:
On
Alarm:
Display:
Numeric:
Graphic:
Stored
Instrument
Setups:
Display
Type &
Use:
Resolution:
Technology:
Internal, externalor automatic
Freezes meas. result until a
new
measurement
is initiated
via Restart.
Removes
(blanks) 1 to 13
digits from the
calculated
result
before
displaying
it.
Annunciator
on display
and/or SRQ via GPIB
Lower limit (limit 1)
Upper limit (limit 2)
Off
Alarm if value > limit 2
Alarm if value < limit 1
Alarm if limit 1 < value < limit
2
Alarm if value > limit 2 or
value < limit 1
Stop or Continue
Numeric + graphic
Current
measurement
value
+
annunciator
for limit alarm
Horizontal
line w.
upper/lower
limit markers +
current value marker
20 complete setups can be
saved and recalled from
internal non-volatile memory;
10 can be user protected
Graphicsscreen for menu
control, numerical readout (14
digits) and status info
320 x 97 pixels
Monochrome
LCD with
white LED backlight
GPIB Interface
Programmable
Functions:
Compatibility:
Modes:
Agilent
Compatibility:
Interface
Functions:
Max.
Meas.
Rate
Via
GPIB:
To
Internal
Memory:
Internal
Memory
Size:
Data
Output:
All front panel accessible
functions
IEEE 488.2-1987,
SCPI 1999
Native mode
Agilent
compatible
mode
HP 53131/132/181 commands
are emulated. Code and
response format is compatible
No timing compatibility. No
resolution
compatibility
SH1, AH1, T6, L4, SR1,
RL1, DC1, DT1, E2
2000
readings/s
(block)
350 readings/s (individual)
250 k readings/s
Up to 750 k readings
ASCII, IEEE double precision
floating point
USB Interface
Version:
2.0, 12 Mb/s
Protocol:
USBTMC-USB488
TimeView™
This software package is intended for advanced
Modulation Domain analysis and runs on any
32-bit Windows® system.
■ Data Capture Modes &
Measurement
Rate
Effective rate depends on measurement
function and internal data format.
Free-running
Measurement:
Repetitive
Sampling:
Continuous
Single
Period:
Waveform
Capture:
Data
Analysis
Features:
250 k readings/s
Up to 100 Msa/s equiv
sample rate (10 ns between
samples)
Yes, from LF to 250 kHz
repetition
rate
Yes
Measurement
data vs time
Cursor measurements
Distribution
histogram
FFT graph w. Hamming,
Hanning and other relevant
filters
Smoothing
Zoom
Setup,
measurement
data
archive and printing
Zero dead time ADEV and
MADEV vs.
Battery Unit
Option 23/90
Battery
Type:
Ext. DC
Input:
Connector:
Oper. &
Charg.
Temp.
Range:
Storage:
Operating
Time
(@ +25
°C):
Charging:
Charging
Time
(@ +25
°C):
Status Indicator:
Weight:
Li-Ion, 22.2 V, 90 Wh
12 to 18 V, max 6 A
XLR male, 3-pin
0 to +40 °C
-20 to +60 °C (1 month)
-20 to +45 °C (3 months)
-20 to +20 °C (1 year)
ON: >4.5 h
Stby: >24 h
Automatic,
when ext. AC or
DC is connected
<8.5 h
On-screen
w. low battery
warning
1.2 kg
Specifications
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
