General
Specifications
Environmental Data
Class:
MIL-PRF-28800F, Class 3
Operat. Temp:
0 °C to +50 °C
Storage Temp:
-40 °C to +71 °C
Humidity:
5-95 % @ 10-30 °C
5-75 % @ 30-40 °C
5-45 % @ 40-50 °C
Max. Altitude:
4600 m
Vibration:
Random and sinusoidal per
MIL-PRF-28800F, Class 3
Shock:
Half-sine 30G per
MIL-PRF-28800F; bench
handling
Transit Drop
Test:
Transport box tested according
to UN-D 1400 drop test program
1.
Heavy-duty transport case and
soft carrying case tested
according to MIL-PRF-28800F.
Reliability:
MTBF 30000 h, calculated
Safety:
Designed and tested for
Measurement Category I,
Pollution Degree 2, in
accordance with EN/IEC
61010-1:2001 and
CAN/CSA-C22.2 No.
61010-1-04 (incl. approval)
EMC:
EN 61326 (1997) A1 (1998),
increased test levels per EN
50082-2,Group 1, Class B, CE
Power Requirements
Line Voltage:
90-265 V
RMS
, 45-440 Hz
Power
Consumption:
<40 W
Dimensions & Weight
Width:
% x 19" (210 mm)
Height:
2U (90 mm)
Depth:
395 mm
Weight:
Net 2.7 kg (5.8 lb)
Shipping appr. 3.5 kg
(7.5 lb)
Ordering
Information
Basic Model
s
CNT-90XL-27G\
\40G\46G\60G:
27 /40 /46 /60 GHz
Microwave Frequency
Counter/Analyzer including
medium stability OCXO
timebase
Included with
Instrument:
36 months product warranty,
line cord, brochure with
important information;
'getting started' manual,
user's manual, and
programmer's handbook on
CD;
Certificate of Calibration.
RF Input Versions
-27G:
27 GHz Input C
-40G:
40 GHz Input C
-46G:
46 GHz Input C
-60G:
60 GHz Input C
Timebase Options*
Option 30/90:
Very high stability OCXO
Option 40/90:
Ultrahighstability OCXO
* Option 19/90 Medium Stability OCXO timebase is
the standard
oscillator in all CNT-90XL models
Pulsed RF Option
Option 28: Pulsed RF measurements
Optional
Accessories
Option 22/90:
Rackmount kit
Option 23/90:
Battery supply unit
Option 27:
Carrying case
Option 27H:
Heavy-duty hard transport
case
Option 29/90:
TimeView modulation
domain analysis SW for
CNT-90XL
Option 90/01:
Cal. certificate w. protocol;
standard oscillator
Option 90/06:
Cal. certificate w. protocol;
oven oscillator
Option 90/00:
Cal. certificate w. protocol;
hold-over frequency
aging/week
Option 95/05:
5 years extended warranty
Printed Manuals:
GS-90-DE * Getting Started German
GS-90-ENG * Getting Started English
GS-90-FR *
Getting Started French
OM-90 * User’s Manual
PM-90 * Programmer’s Handbook
SM-90
Service Manual
* Included as PDF-file upon shipment
Specifications
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
8-24
