Pendulum CNT-90 Series User Manual

Specifications
Introduction
Only values with tolerances or limits are guar-
anteed data. Values without tolerances are in-
formative data, without guarantee.
Measurement
Functions
Refer to page 8-55 for uncertainty informa-
tion.
Inputs A and B can be swapped in all modes
except Rise Time and Fall Time.
Display: All measurements are displayed
with a large main parameter value and smaller
auxiliary parameter values (with less
resolution). Some measurements are only
available as auxiliary parameters.
Frequency A, B, C
■ Range:
Input A:
0.002 Hz - 400 MHz
Input B:
0.002 Hz - 400 MHz
Input C:
100 MHz - 3 GHz (Opt. 10)
300 MHz - 8 GHz (Opt. 13)
200 MHz - 15 GHz (Opt. 14)
200 MHz - 20 GHz (Opt. 14B)
Resolution:
12 digits/s
■ Display:
Main Parameter:
Period
,
V
,
V
min
Aux. Parameter(A, B):
V
max p-p
Frequency Burst A, B, C
Frequency and PRF of repetitive burst signals
can be measured without external control sig-
nal and with selectable start arming delay.
Functions:
Frequency in burst (Hz)
PRF (Hz)
Number of cycles in burst
Range A, B, C:
See Frequency A, B, C
Min. Burst
Duration:
40 ns (80 ns > 160 MHz)
Min. No. of Pulses
in Burst (Inp A, B):
3 (6 above 160 MHz)
(Inp C):
3 x prescaler factor
PRF Range (see
also Inp C spec):
0.5 Hz - 1 MHz
Start Delay
10 ns - 2 s, resolution 10
Range:
ns
■ Display:
Main Parameter:
Frequency in burst
Aux. Parameters:
PRF & number of cycles in
burst (Ch A or Ch B only)
Period A, B, C Average
■ Range:
Input A, B:
2.5 ns - 500 s
Input C (3 GHz):
330 ps - 10 ns
(8 GHz):
125 ps - 3.3 ns
(15 GHz):
72 ps - 5 ns
(20 GHz):
50 ps - 5 ns
Resolution:
12 digits/s
■ Display:
Main Parameter: Frequency
Aux. Parameter (A B): V
max
,V
min
,V
p-p
8-3
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
