Pendulum CNT-90 Series User Manual

Specifications
Limit Qualifier:
Meas. Pacing
Time Range:
Equidistancy:
Mathematics
Functions:
Off
Capture & store values above
limit 2 Capture & store values
below limit 1
Capture & store values inside
limits 1 and 2 Capture & store
values outside limits 1 and 2
2 µs - 500 s
±(2
µ
s + 0.1% of pacing time)
K*X+L, K/X+L, (K*X+L)/M,
(K/X+L)/M and X/M-1 X is
current reading. K, L and M
are constants, set via
keyboard or as frozen
reference value (X
0
).
Other Functions
Measuring Time:
20 ns - 1000 s for Smart Period
AVG & Smart Frequency; 20 ns
- 2 s for PRF, Freq. in Burst,
normal Period AVG & normal
Frequency; 4 s - 500 s for
TIE, Freq.& Period
back-to-back; Single cycle for
other meas. functions. Times
>2 s are software controlled w.
reduced resolution and
accuracy.
Timebase
Internal, external or automatic
Reference:
Display Hold:
Freezes meas. result until a
new measurement is initiated
via Restart.
Digit Blanking:
Removes (blanks) 1 to 13 digits
from the calculated result
before displaying it.
Limit Alarm:
Annunciator on display and/or
SRQ via GPIB
Limit Values:
Lower limit (limit 1)
Upper limit (limit 2)
Settings:
Off
Alarm if value > limit 2
Alarm if value < limit 1
Alarm if limit 1 < value < limit 2
Alarm if value > limit 2 or value
< limit 1
On Alarm:
Stop or Continue
Display:
Numeric + graphic
Numeric:
Current measurement
value + annunciator for limit
alarm
Graphic:
Horizontal line w.
upper/lower limit markers +
current value marker
Stored Instrument
20 complete setups can be
Setups:
saved and recalled from
internal non-volatile memory;
10 can be user protected.
Stored Datasets:
In statistics mode w. HOLD
activated, 8 datasets w. max.
32000 samples can be saved
and recalled from internal
non-volatile memory.
Display
Type & Use:
Graphics screen for menu
control, numerical readout (14
digits) and status info
Resolution:
320 x 97 pixels
Technology:
Monochrome LCD with
white LED backlight
GPIB Interface
Programmable
All front panel accessible
Functions:
functions
Compatibility:
IEEE 488.2-1987,
SCPI 1999
Modes:
Native mode
Agilent compatible mode
Agilent
HP 53131/132/181 com-
Compatibility:
mands are emulated. Code
and response format is
compatible. No timing
compatibility. No resolution
compatibility.
8-53
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
