INTELLIPRO
®
Variable Speed Pump Installation and User’s Guide
18
INTELLIPRO
®
Variable Speed Pump Installation and User’s Guide
To connect the IntelliPro
®
Variable Speed Pump
communication cable to EasyTouch
®
or IntelliTouch
®
Control System load center:
1. Switchthemainpowerofftotheloadcenter.
2. Unlatchthetwoenclosuredoorspringlatch,and
open the door.
3. Remove the two retaining screws securing the
high voltage cover panel, and remove it from the
enclosure.
4. Loosenthetwoaccessscrewssecuringthecontrol
panel.
5. Lowerdownthehingedcontrolpaneltoaccessthe
EasyTouch or IntelliTouch system circuit board.
6. Route the communication cable into the plastic
grommet(locatedonthelowerleftsideoftheload
center),upthroughthelowvoltageracewaytothe
EasyTouch or IntelliTouch system circuit board.
7. Stripbackthecableconductors6mm(1/4”).Insert
thetwowiresintotheCOMportscrewterminals
ontheEasyTouchand/orIntelliTouchsystemcircuit
board. Secure the wires with the screws.
8. EasyTouch COM port (J20): ConnecttheGREEN
(#2)andYELLOW(#3)wirestotheCOMportscrew
terminals(#2and#3).Besuretomatchthecolor
coding of the wires;YELLOW toYELLOWand
GREENtoGREEN.TheRedwireisnotconnected.
Secure the wires with the screws.
IntelliTouch COM port (J7/8):
ConnecttheGREEN
(#2)andYELLOW(#3)wirestotheCOMport(J20)
screwterminals(#2and#3).Besuretomatchthe
colorcodingofthewires;YELLOWtoYELLOWand
GREENtoGREEN.TheRedwireisnotconnected.
Secure the wires with the screws.
Note: Multiplewiresmaybeinsertedintoasingle
screw terminal.
9. Close the control panel into its original position
and secure it with the two screws.
10. Installthehighvoltagecoverpanelandsecureit
with the two retaining screws.
11. Closetheloadcenterfrontdoor.Fastenthespring
latch.
12. Switchthepowerontotheloadcenter.
EasyTouch/IntelliTouchControlSystem
LoadCenter
Control Panel
AccessScrew
HighVoltage
Cover Panel
RetainingScrews
(forHighVoltage
CoverPanel)
FrontDoor
Grommet(toLow
VoltageRaceway)
Control Panel
AccessScrew
EasyTouch Control System Circuit Board
Indoor Control Panel
IntelliChlor
IntelliPro
RF Transceiver
EasyTouch
COMPORT
(J20)
IntelliTouch Control System Circuit Board
BLK
GRN
YEL
RED
IntelliTouch Personality
BoardCOMPORT
(J7/J8)
