PUMP OVERVIEW
The IntelliPro
®
Variable Speed Pump can be
programmed to run at specific speeds and time
intervals for maximum operating efficiency and energy
conservation for a variety of inground pools.
External Control
IntelliTouch, EasyTouch, SunTouch control systems
and IntelliComm communication centers can remotely
control the IntelliPro Variable Speed pump. The pump’s
communications address and other functions are
accessible from the pump’s control panel.
• Thepumpcanoperatefrom450RPMto3450RPM
withfourpresetspeedsof750,1500,2350and3110
RPM
• Thepumpcanbeadjustedfromthecontrolpanelto
runatanyspeedbetween450RPMto3450RPM
for different applications
• Upto8programmablespeeds
• PumpcontrolpanelalarmLEDanderrormessages
warn the user against under and over voltage, high
temperature, over current and freeze protection
• CommunicateswithEasyTouch
®
, IntelliTouch
®
or
SunTouch
®
Control Systems or an IntelliComm
®
CommunicationCenterviaatwo-wireRS-485
cable connection
• Self-primingforeasystart-up
• Compatiblewithmostcleaningsystems,lters,and
jetactionspas
• UL/CUL/NSFListed
Drive Assembly and Control Panel
The IntelliPro pump drive assembly consists of an
operator control panel and the system electronics that
drive the motor. The drive microprocessor controls
the motor by changing the frequency of the current it
receives together with changing the voltage to control
the rotational speed.
Motor Features
• PermanentMagnetSynchronousMotor(PMSM)
• Highefciency(3450RPM92%and1000RPM
90%)
• Superiorspeedcontrol
• Operatesatlowertemperaturesduetohigh
efficiency
• Sametechnologyasdeployedinhybridelectric
vehicles
• Designedtowithstandoutdoorenvironment
• Totallyenclosedfancooled
• Three-phasemotor
• 56SquareFlange
• Six-Pole
• Lownoise
• RS-485commincationcableincluded
• IntelliTouchsystemscontrol8IntelliPropumpsusing
8speedsperpump.
• EasyTouch systemscontrol2IntelliPropumpsusing
8speedsperpump.
• SunTouchsystemscontroloneIntelliPropumpusing
8speeds.
• IntelliComm systems control one IntelliPro pump
usingthe4ExternalControlprograms.
IntelliProVariableSpeedDriveAssembly
MotorStand
OperatorControlPanel,
ButtonsandLED
ACPowerConnection
Compartment
Communication port for connection to
EasyTouch, IntelliTouch or SunTouch
control system or IntelliComm
communication center via two-wire
RS-485cable(notshown)
