INTELLIPRO
®
Variable Speed Pump Installation and User’s GuideINTELLIPRO
®
Variable Speed Pump Installation and User’s Guide
Electrical Wiring Installation
To connect the IntelliPro
®
VariableSpeedPumptoanACpowersource:
1. Besureallelectricalbreakersandswitchesareturned
off before wiring motor.
2. Besurethatthesupplylinevoltagematchesthemotor
voltagelistedonthemotorplate(example230VAC
or115VAC).Iftheydonotmatch,permanentmotor
damage may occur.
3. Forwiringsizesandgeneralguidelinesforproper
electrical installation, please follow the specifications
denedintheNationalElectricCodeandanylocal
codes as required.
4. Usestrainreliefandbesureallelectricalconnections
are clean and tight.
5. Cutthewirestotheappropriatelengthsotheydo
not overlap or touch when connected.
6. Permanentlygroundthemotorusingthegreenground
wire,asshownbelow.Usethecorrectwiresizeand
typespeciedbyNationalElectricalCode.Makesure
the ground wire is connected to an electrical service
ground.
7. Bond the motor to the structure in accordance with
the National Electrical Code. Use a solid copper
bondingconductornotsmallerthan8AWG.Runa
wire from the external bonding screw or lug to the
bonding structure.
8. Connectthewirefromtheaccessiblebondinglugon
the motor to all metal parts of the swimming pool, spa,
or hot tub structure and to all electrical equipment,
metalconduit,andmetalpipingwithin5feet(1.52
meters) of the inside walls of the swimming pool,
spa,orhottub.ForCanada,a6AWGorlargersolid
copper bonding conductor is required.
9. Thepumpshouldbepermanentlyconnectedtoeither
acircuitbreaker,2-poletimeror2-polerelay.IfAC
powerissuppliedbyaGFCIcircuitbreaker,usea
dedicatedcircuitbreakerthathasnootherelectrical
load electrical loads.
10. IMPORTANT: When connecting the pump to an
automation system (IntelliTouch
®
, EasyTouch
®
,
SunTouch
®
Control Systems and IntelliComm
®
CommunicationCenter), continuous power must be
supplied to the pump by connecting it directly to the
circuitbreaker.Whenusinganautomationsystem,
be sure that no other lights or appliances are on the
same circuit.
Note: When the pump is started and stopped by
removing power with a relay or timer, a two-pole
device should be used to apply and remove power
tobothPOWERLINETERMINALS.
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. This pump must be installed by a licensed or certified electrician or
a qualified service professional in accordance with the National Electrical Code and all applicable local codes and ordinances.
Improper installation will create an electrical hazard which could result in death or serious injury to users, installers, or others
due to electrical shock, and may also cause damage to property.
Always disconnect power to the pump at the circuit breaker before servicing the pump. Failure to do so could result in
death or serious injury to service people, users or others due to electric shock.
Read all servicing instructions before working on the pump.
Pentair offers 2-Pole 20 Amp GFCI breakers
(P/N PA220GF) which offer 6 milliamp personnel
protection while meeting 2008 to current NEC
Standards for Pool Pumps.
GroundWire
Connection
BondingLug
FieldWiringCompartment
