>Reboot>Reboot?(Yes/No) (toreboottheunit)
>Factorydefault >Factorydefault?(Yes/No) (torestorefactorydefaults)
>LANconfig 
>Portspeed (showsportspeed:Auto,10baseTFD,10baseTHD,
>LAN 100baseTxFD,100baseTxHD,1000baseTxFD)
>WAN1 
>WAN2
>WAN3*

*LayoutcontinuesassuchforallavailableWANports

10 Installation
ThefollowingsectiondetailsconnectingthePeplinkBalancetoyournetwork:
10.1 Preparation
BeforeinstallingyourPeplinkBalance,pleasepreparethefollowing:
● AtleastoneInternet/WANaccessaccount
● Foreachnetworkconnection,one10/100BaseTUTPcablewithRJ45connector,one1000BaseT
Cat5EUTPcablefortheGigabitport,oroneUSBmodemfortheUSBWANport
● AcomputerwiththeTCP/IPnetworkprotocolandawebbrowserinstalled—Supportedbrowsers
includeMicrosoftInternetExplorer11orabove,MozillaFirefox24orabove,AppleSafari7or
above,andGoogleChrome18orabove.
10.2 ConstructingtheNetwork
Atthehighlevel,constructthenetworkaccordingtothefollowingsteps:
1. WithanEthernetcable,connectacomputertooneoftheLANportsonthePeplinkBalance.For
PeplinkBalancemodelsthatsupportmultipleconnections,repeatwithdifferentcablesforuptofour
computerstobeconnected.
2. WithanotherEthernetcable,connecttheWAN/broadbandmodemtooneoftheWANportsonthe
PeplinkBalance.Repeatusingdifferentcablestoconnectfromtwoto13WAN/broadband
connectionsorconnectaUSBmodemtotheUSBWANport.
3. ConnecttheprovidedpoweradapterorcordtothepowerconnectoronthePeplinkBalance,and
thenplugthepoweradapterintoapoweroutlet.
 

