IPsecVPNSettings
Name
Thisfieldisforspecifyingalocalnametorepresentthisconnectionprofile.
Active
Whenthisboxischecked,thisIPsecVPNconnectionprofilewillbeenabled.Otherwise,it
willbedisabled.
ConnectUpon
Disconnection
of
CheckthisboxandselectaWANtoconnecttothisVPNautomaticallywhenthespecified
WANisdisconnected.Toactivatethisfunction,clickthe buttonnexttothe“Active”
option.
Remote
GatewayIP
Address/
HostName
Entertheremotepeer’spublicIPaddress.ForAggressiveMode,thisisoptional.
Local
Networks
EnterthelocalLANsubnetshere.Ifyouhavedefinedstaticroutes,theywillbeshown
here.

UsingNAT,youcanmapaspecificlocalnetwork/IPaddresstoanother,andthepackets
receivedbyremotegatewaywillappeartobecomingfromthemappednetwork/IP
address.ThisallowyoutoestablishIPsecconnectiontoaremotesitethathasoneor
moresubnetsoverlappedwithlocalsite.

TwotypesofNATpoliciescanbedefined:

OnetoOneNATpolicy:ifthedefinedsubnetinLocalNetworkandNATNetworkhas
thesamesize,forexample,policy"192.168.50.0/24>172.16.1.0/24"willtranslatethe
localIPaddress192.168.50.10to172.16.1.10and192.168.50.20to172.16.1.20.Thisis
abidirectionalmappingwhichmeansclientsinremotesitecaninitiateconnectiontothe
localclientsusingthemappedaddresstoo.

ManytoOneNATpolicy:ifthedefinedNATNetworkontherighthandsideisanIP
address(orhavinganetworkprefix/32),forexample,policy"192.168.1.0/24>
172.168.50.1/32"willtranslateallclientsin192.168.1.0/24networkto172.168.50.1.This
isaunidirectionalmappingwhichmeansclientsinremotesitewillnotbeabletoinitiatea
connectiontothelocalclients.
Remote
Networks
EntertheLANandsubnetsthatarelocatedattheremotesitehere.
Authentication
ToaccessyourVPN,clientswillneedtoauthenticatebyyourchoiceofmethods.Choose
betweenthePresharedKeyandX.509Certificatemethodsofauthentication.
Mode
ChooseMainModeifbothIPsecpeersusestaticIPaddresses.ChooseAggressive
ModeifoneoftheIPsecpeersusesdynamicIPaddresses.
ForceUDP
ForforcedUDPencapsulationregardlessofNATtraversal,tickthischeckbox.

