Pepwave HD2 User Manual

Access Control
Restricted
Mode
The settings allow administrator to control access using MAC address filtering. Available
options are None, Deny all except listed, Accept all except listed, and RADIUS MAC
Authentication.
When WPA/WPA2 - Enterprise is configured, RADIUS-based 802.1 x authentication is
enabled. Under this configuration, the Shared Key option should be disabled. When using
this method, select the appropriate version using the V1/V2 controls. The security level of this
method is known to be very high.
When WPA/WPA2- Personal is configured, a shared key is used for data encryption and
authentication. When using this configuration, the Shared Key option should be enabled. Key
length must be between eight and 63 characters (inclusive). The security level of this method
is known to be high.
The configuration of Static WEP parameters enables pre-shared WEP key encryption.
Authentication is not supported by this method. The security level of this method is known to
be weak.
MAC Address
List
Connection coming from the MAC addresses in this list will be either denied or accepted
based the option selected in the previous field.
RADIUS Server Settings
Host
Enter the IP address of the primary RADIUS server and, if applicable, the secondary RADIUS
server.
Secret
Enter the RADIUS shared secret for the primary server and, if applicable, the secondary
RADIUS server.
http://www.peplink.com
147
Copyright @ 2017 Pepwave

Pepwave HD2 Specifications

General

Category	Network Router
Model	Pepwave HD2
WAN Ports	2
LAN Ports	4
Cellular Modems	2
Throughput	400 Mbps
Load Balancing	Yes
VPN	Yes
GPS	Yes
Wireless Standards	802.11a/b/g/n/ac
Ethernet Ports	4
Firewall	Yes
Cellular Connectivity	3G/4G LTE
VPN Support	IPsec, PPTP, L2TP
