Pepwave HD2 User Manual

Cellular
OFF
Disabled or no SIM card inserted
ON
Connecting or connected to network(s)
LAN and Ethernet WAN Ports
Green LED
ON
100 Mbps
OFF
10 Mbps
Orange LED
ON
Port is connected without traffic
Blinking
Data is transferring
OFF
Port is not connected
Port Type
Auto MDI/MDI-X ports
4.10 MAX BR1 Pro LTE
4.10.1 Panel Appearence
4.10.2 LED Indicators
● The statuses indicated by the front panel LEDs are as follows:
Status Indicators
Status
OFF
System initializing
Red
Booting up or busy
Blinking
Boot up error
http://www.peplink.com
27
Copyright @ 2017 Pepwave

Pepwave HD2 Specifications

General

Category	Network Router
Model	Pepwave HD2
WAN Ports	2
LAN Ports	4
Cellular Modems	2
Throughput	400 Mbps
Load Balancing	Yes
VPN	Yes
GPS	Yes
Wireless Standards	802.11a/b/g/n/ac
Ethernet Ports	4
Firewall	Yes
Cellular Connectivity	3G/4G LTE
VPN Support	IPsec, PPTP, L2TP
