Pfaff 3834-14/11 User Manual

15 - 1
Circuit diagrams
15 Circuit diagrams
Reference list for circuit diagrams
A1 Controller Quick P 320MS
A2 Control panel T1
A14 Sewing head identification
A100 Thread strength module
A101 Thread strength solenoid and key
(release thread strength solenoid)
B10 Initiator material height
H1 Sewing lamp
H20 LED Stitch counter
M1 Sewing motor
M2 Stepping motor feed wheel
M3 Stepping motor roller presser
M45 Pullermotor
Q1 Main switch
R45 Resistance 330 ohm
S1 Pedal set value transmitter
S2 Pedal 2 Fullness
S21 Manual backtacking key
S22 Single stitch switch
S23 Needle position change switch
S24 Start inhibitor switch
S26 Knee switch (program)
S101 Key (release thread strength
solenoid)
XP1 Pedal set value transmitter
XP2 Pedal Fullness
X1 Mains plug
X1A RS232 – interface 1
Control panel T1
X1B VSS Sewing head identification
X3 Incremental transmitter
(sewing motor)
X4A Stepping motor feed wheel
X4B Stepping motor roller presser
X5 Inputs
X8 Sewing motor
X11A CAN interface
X11B Pedal set value transmitter and
fullness
X13 Outputs
X15 Thread monitor
X20 Stepping motor feed wheel
X21 Stepping motor roller presser
X30 Initiator material height
X31 Key row
X34 Start inhibitor
X36 Knee switch (program)
X41 -910/.. Automatic presser foot lift
X42 -900/.. Thread trimmer
X45 R45 Resistor
X101 Power supply A100 and thread
strength solenoid A101
X102 CAN interface
X103 RS232 interface
X110 Thread strength solenoid and key
(release thread strength solenoid)
Y1 -910/.. Automatic presser foot lift
Y2 -900/..Thread trimmer
Y101 Thread strength solenoid
