Mounting and commissioning the machine
8 - 8
8
.03 Mounting the spool holder
● Mount the spool holder as shown in
Fig. 8 - 10.
● Insert the spool holder into the hole in
the table top and affix it with the nuts
enclosed.
Fig. 8 - 10
8.04 Commissioning
● Clean the machine thoroughly and then oil it, or fill in oil, see Chapter 11 Care and
Maintenance.
● Examine the machine, in particular the electric cables, for any damage.
● Have a qualified person check whether the motor can be driven with the existing power
voltage.
If there are any differences, the machine must definitely not be operated!
The machine must only be connected to a suitably earthed socket!
● When the machine is running, the balance wheel must turn towards the operator. If this is not the
case, have the motor adjusted by specialist staff, see Chapter 13.06 Parameter settings.
8.05 Switching the machine on/off
● Switch on the machine, see Chapter 7.01 Main switch.
