Preparation
9 - 2
● Place an empty bobbin 1 onto bobbin winder spindle 2.
● Thread the bobbin in accordance with Fig. 9 - 02 and wind it clockwise around bobbin 1 a
few times.
● Switch on the bobbin winder by pressing the bobbin winder spindle 2 and lever 3 at the
same time.
The bobbin fills up while you are sewing.
If the bobbin is filled outside the sewing operation, the drive for the roller presser,
Puller and the feed wheel should be switched off by pressing the "wind the bob-
bin thread" function. This function is only available in the manual sewing mode.
● The tension of the thread on bobbin 1 can be adjusted with knurled screw 4.
● The bobbin winder stops automatically when bobbin 1 is full.
If the thread is wound unevenly:
● Loosen nut 5.
● Turn thread guide 6 accordingly.
● Tighten nut 5.
9.02 Winding the bobbin thread, adjusting the thread tension
2
1
4
_
+
Fig. 9 - 02
5
6
3
