Adjustment
11 - 63
6 601 Cut
l = yes l
ll = no
607 Max. speed 100 - 2800 2800
609 Cutting speed 1 30 - 300 180
660 Bobbin thread monitoring 0 - 2 0
0 = without
1 = with sensor
2 = with stitch counting
7 700 Needle position 0 0 - 127
Needle reference position
701 Angle setting
I = Synchronizer setting with l
balance wheel
II = Synchronizer setting with
" + " and " - " keys
702 Needle position 1 (needle lowered) 0 - 127 40
703 Needle position 2 0 - 127 117
(take-up lever raised)
705 Needle position 5 0 - 127 90
(end cutting signal 1)
707 Needle position 9 0 - 127 100
(Start thread tension release)
11.09 Parameter settings
Following parameters can be set on the control panel using the display:
For more displays and information see the motor instruction manual.
Group
Parameter
Significance Setting Standard value
