13 - 1
Circuit diagrams
A1 Quick controller
A2 OC TOP operating panel
C1 Starting capacitor knife motor
H1 Sewing lamp
H10 LED stitch counting
K1 Relay knife motor
M1 Sewing motor
M10 Knife motor
Q1 On/off switch
T10 Transformer knife motor
Outputs
Y1 900/..thread trimmer
Y4 910/..automatic presser foot lift
Y5 911/..backtacking mechanism
Y10 Thread tension
Inputs
S1 Pedal set value transmitter
S10 Key knife motor
S11 Key backtacking by hand
S12 Key single stitch
S13 Key needle position change
S14 Key start inhibitor
Reference list for the circuit diagrams
