Pfaff 591

Setting up
9 - 7
61-016
61-016
6
1-007
Fig. 9 - 08
3
1
2
9
.08 Setting the stitch length
● Press key 1 and at the same time turn the balance wheel until the stitch setter clicks into
position.
● Hold down key 1 and turn the balance wheel to and fro until the stitch length required is
shown on the scale 2 opposite the bottom edge 3 of the belt guard recess.
