Care and maintenance
10 - 5
10
12
0
6
4
2
8
16
14
100
50
150
0
200
230
Fig. 10 - 07
10
.07
Checking/adjusting the air pressure
●
Before operating the machine, always
check the air pressure on gauge
1
.
●
Gauge
1
must show a pressure of
6 bar
.
●
If necessary adjust to this reading.
●
To do so, pull knob
2
upwards and turn it
so that the gauge shows a pressure of
6
bar
.
2
1
44
46
