Adjustment
11 - 34
11.04.30 Lubrication
Requirement
After a running time of 10 seconds a fine line of oil should form on a strip of paper held next
to the hook.
● Check whether oil has been filled in and that there is no air in the oil lines.
● Let the machine run for 2-3 min..
While the machine is running do not place hands in the needle or hook area!
Danger of injury from moving parts!
● With the machine running hold a strip of paper on the hook and check the requirement.
● If necessary, adjust the oil flow on screw 1.
Fig. 11 - 30
