Pfaff 591

Adjustment
11 - 47
61-057
11.06.05 Knife stroke
Requirement
The knife stroke can be adjusted over a range from 1.0 to 3.5 mm, allowing the best
possible adaption to all materials used.
Fig. 11 - 43
● Turn eccentric 1 (screws 2) on the back of the sewing head so that the marking of the
desired cutting stroke is opposite marking 3.
2
1
3
