11.06.02 Knife position crosswise to sewing direction
Requirement
When the edge trimmer is engaged, knife 2 must be vertical and rest lightly on the needle
plate insert.
Fig. 11 - 40
● Switch off the machine and engage the edge trimmer.
● Bring the knife into a vertical postion by turning milled screw 1.
● Bring knife 2 into light contact with the needle plate insert and tighten screw 3.
The cutting pressure can be adapted to the material used with milled screw 1.
+
-
1
3
2
