Pfaff creative 3.0 User Manual

2:9
Preparations
Changing the presser foot
Remove presser foot
Press the presser foot downwards until it
disengages from the presser foot holder.
Attach presser foot
Line up the pins on the foot with the gap underneath
the presser foot holder. Press upwards until the foot
snaps into place.
You can also use the presser foot up/down buttons
to raise or lower the presser foot holder. Place the
presser foot under the presser foot holder, so that
the pins of the foot snap onto the presser foot holder
when lowered.
Changing the needle
1. Use the hole in the multi-purpose tool to hold
the needle.
2. Loosen the needle screw.
3. Remove the needle.
4. Insert the new needle, using the multi-purpose
WRRO3XVKWKHQHZQHHGOHXSZDUGVZLWKWKHÁDW
side away from you until it will go no further.
5. Tighten the needle screw as tight as it will go.
Lowering feed dogs
You can lower the feed dogs by moving the switch
on the front of the sewing machine to the left. Move
the switch to the right if you wish to raise the feed
dogs.
When embroidering the feed dogs are lowered
automatically as the embroidery unit is connected.
When the embroidery unit is removed, the feed
dogs are raised automatically when you start
sewing.

Pfaff creative 3.0 Specifications

General

Sewing and Embroidery Functions	Yes
Display	Color Touch Screen
Built-in Stitches	254
USB Connectivity	Yes
Automatic Thread Cutter	Yes
Type	Computerized Sewing and Embroidery Machine
Number of Stitches	254
Built-in Embroidery Designs	157
Needle Threader	Automatic
Bobbin Winding	Automatic
Presser Feet	Included
Automatic Needle Threader	Yes
Speed Control	Yes
USB Port	Yes
Built-in Memory	Yes
Stitch Length	6 mm
LCD Screen	Color Touch Screen
Stitch Width	9 mm
Max Sewing Speed	800 stitches per minute
