Specifi cations
10
3 Specifi cations
▲
Rated values
Voltage: .......................................................................................................230 V, single-phase
Frequency: .................................................................................................................. 50/60 Hz
Current for drive: ...............................................................................................................5.0 A
Current for control unit: .....................................................................................................0.6 A
Power output: .................................................................................................................550 W
Speed: ...................................................................................................................... 4000 min
-1
Torque: ...........................................................................................................................1.2 Nm
Moment of inertia of motor (without belt pulley): .....................................................1.0 kgcm2
Operating mode: ..........................................................S5 (40% rel. on-time for 2.5 s runtime)
Protection system: .............................................................................................................IP40
Insulation class: ......................................................................................................................E
Limit values
Rated voltage range: ......................................................................... 180 – 260 V, single-phase
Max. motor speed: .................................................................................................. 4500 min
-1
Max. torque (short time): ............................................................................................... 7.0 Nm
Max. power output (short-time): ...................................................................................1500 W
Moment of inertia of machine (reduced to motor shaft): ..........................................9.0 kg cm
²
Before connecting the sewing machine drive make sure that the mains voltage
is in the specifi ed rated voltage range.
Operating requirements
Ambient temperature: .......................................................................................... +5 to +45° C
Average ambient temperature (over 24 hours): .............................................................<35° C
Relative humidity: ................................................................................................85% at 30° C
External control elements
Voltage with engine idling: ................................................................................................. 25 V
Voltage under load: ......................................................... 24 V at 4A / 20 V at 10 A (short-time)
Output:
P45 PD2-L .........................................................................................96W / 200 W (short-time)
P74 ED-L ........................................................................................ 192 W / 400 W (short-time)
Load current: ........................................................................................................................4 A
Max. load current (short-time): ........................................................................................... 10 A
The sum of the load currents of all simultaneously activated control elements
must not continuously exceed 4 A .
Weights
Net weight (drive complete with all accessories): .................................................approx. 9 kg
Gross weight: ....................................................................................................... approx. 11 kg
▲
Subject to alteration
